15mm Mini-Servo CLS0808M, HV, ALU, MG
CLS0808M
High-end miniservo of 15mm class with metal gear and aluminum housing
The CLS0808M 15mm Mini Servo is a high-end, fast-performing servo for advanced RC applications. Featuring metal gears for durability and smooth operation, it is designed for precision and reliability.
With high-voltage (HV) capability up to 8.4V, this servo ensures consistent performance in demanding setups. Its aluminum housing provides enhanced strength and efficient heat dissipation, making it ideal for high-performance models requiring speed and accuracy. The CLS0808M is a top choice for RC enthusiasts looking for a compact yet powerful servo in the 15mm class.
Dead band: 2μs
Working frequence: 1520μs / 330hz
Operating Voltage: DC4.8~8.4 V
Operating Speed (6.0V): 0.11sec/60 degrees
Operating Speed (7.4V): 0.08sec/60 degrees
Operating Speed (8.4V): 0.06sec/60 degrees
Stall Torque (6.0V): 6.0kg.cm
Stall Torque (7.4V): 8.0kg.cm
Stall Torque (8.4V): 9.5kg.cm
Dimentions: 35.5x15x28.5mm
Weight: 34g
Bearings: 2BB
Connector Wire Length: JR265 mm
Spline: 25T (Futaba)
| Stall Torque (8.4V): 9.5kg.cm |
| Stall Torque (7.4V): 8kg.cm |
| Stall Torque (6V): 6kg.cm |
| Blokiermoment(5V): 5kg.cm |
| Speed (8.4V): 0.06/60° |
| Speed (7.4V): 0.08sec/60° |
| Speed (6V): 0.11s/60° |
| Geschwindigkeit(5V): 0.13s/60° |
| Family: 15mm Mini |
| Weight: 34g |
| Gear: Metall |
| Body: Aluminum |
| Ball Bearings: 2BB |
| Motor: Coreless |
| Softstart: No |
| Programmable: Yes |
| Axis: 5.90/25T/Futaba |
| Width: 15mm |
| Length: 35.5mm |
| Height: 28.5mm |
Internal Reference:
CLS0808M
